Filter Material: ABS
Flame Retardant Rating: UL94-V0 (Extra)
IP Rating: IP54
| Model | TK3322.230-EMC | |
| Color | RAL7035 | RAL7032 |
| Material Code | 1011009 | 1011010 |
| Axial Fan | ZF-120S-230 | |
| Rated Operating Voltage (V/Hz) | 230/50/60 | |
| Airflow, Free Blowing | 55/56m³/h | |
| Airflow with Outlet Filter | 1xTK3322.300:43/50m³/h 2xTK3322.300:48/58m³/h | |
| Axial Flow Fan | Automatic Shaded Pole Motor | |
| Rated Current (A) | 0.12/0.1 | |
| Power (W) | 19/14 | |
| Noise Level (dB) | 50/52 | |
| Operating Temperature Range | -10℃ to +55℃ | |
| Outlet Filter Model | TK3322.300-EMC（RAL7035/RAL7032）1011015/1011016 | |
| Model | TK3322.115-EMC | |
| Color | RAL7035 | RAL7032 |
| Material Code | 1011011 | 1011012 |
| Axial Fan | ZF-120S-115 | |
| Rated Operating Voltage (V/Hz) | 115/50/60 | |
| Airflow, Free Blowing | 55/56m³/h | |
| Airflow with Outlet Filter | 1xTK3322.300:43/50m³/h 2xTK3322.300:48/58m³/h | |
| Axial Flow Fan | Automatic Shaded Pole Motor | |
| Rated Current (A) | 0.24/0.20 | |
| Power (W) | 18/15 | |
| Noise Level (dB) | 50/52 | |
| Operating Temperature Range | -10℃ to +55℃ | |
| Outlet Filter Model | TK3322.300-EMC（RAL7035/RAL7032）1011015/1011016 | |
| Model | TK3322.024-EMC | |
| Color | RAL7035 | RAL7032 |
| Material Code | 1011013 | 1011014 |
| Axial Fan | ZF-120B-024 | |
| Rated Operating Voltage (V/Hz) | 24DC | |
| Airflow, Free Blowing | 55/56m³/h | |
| Airflow with Outlet Filter | 1xTK3322.300:43/50m³/h 2xTK3322.300:48/58m³/h | |
| Axial Flow Fan | Direct Current Motor | |
| Rated Current (A) | 0.30 | |
| Power (W) | 3.5 | |
| Noise Level (dB) | 50/52 | |
| Operating Temperature Range | -10℃ to +55℃ | |
| Outlet Filter Model | TK3322.300-EMC（RAL7035/RAL7032）1011015/1011016 | |
Note: Standard with PA66 plastic grill. For special voltage requirements or other grill types, please contact our company.
